RAK2245 User Manual V1.2
Table 8 | TX RF Characteristics
2.12.2 Receiver RF Characteristics
It is highly recommended, to use optimized RSSI calibration values, which is
part of the HAL v3.1. For both, Radio 1 and 2, the RSSI-Offset should be set -
169.0. The following table gives typically sensitivity level of the RAK2245.
Table 9 | RX RF Characteristics
TX Power Variation vs.
Temperature
-5dBm
+5dBm
TX Power Variation
-1.5dBm
+1.5dBm
Signal Bandwidth/[KHz]
Spreading Factor
Sensitivity/[dBm]
125
12
-139
125
7
-126
250
12
-136
250
7
-123
500
12
-134
500
7
-120
