SERVICING AND MAINTENANCE 311
Cavity Cartridge Fuse Micro Fuse Description
F01 80 Amp Black – Rad Fan Control Module – If Equipped
F03 60 Amp Yellow – Rad Fan – If Equipped
F05 40 Amp Green – Compressor for Air Suspension – If Equipped
F06 40 Amp Green – Antilock Brakes/Electronic Stability Control Pump
F07 40 Amp Green – Starter Solenoid
F08
20 Amp Blue (1500 LD/
Cummins Diesel)
40 Amp Green
–
–
Emissions Diesel – If Equipped
Aux Relay Output- Special Services Only
F09
40 Amp Green (Special
Services Vehicle &
Cummins Diesel)
–
Diesel Fuel Heater – If Equipped / Aux Relay Output-
Special Services Only
F10 40 Amp Green – Body Controller / Exterior Lighting #2
F10 50 Amp Red –
Body Controller / Exterior Lighting #2 – If Equipped with
Stop/Start
F11 30 Amp Pink – Integrated Trailer Brake Module – If Equipped
F12 40 Amp Green – Body Controller #3 / Power Locks
F13 40 Amp Green – Blower Motor
F14 40 Amp Green – Body Controller #4 / Exterior Lighting
F15
–
40 Amp Green
–
–
Spare Fuse
Special Services Only
F16 30 Amp Pink – Smart Bar – If Equipped
8
