SERVICING AND MAINTENANCE 315
F75 – 10 Amp Red Coolant Temperature Valve Actuator
F76 – 10 Amp Red Antilock Brakes / Electronic Stability Control - If Equipped
F77 – 10 Amp Red Drivetrain Control Module/Front Axle Disconnect Module
F78
– 10 Amp Red Engine Control Module / Electric Power Steering
F79 – 15 Amp Blue Clearance Lights
F80 – 10 Amp Red Universal Garage Door Opener / Compass
F81 – 20 Amp Yellow Trailer Tow Right Turn / Stop Lights - If Equipped
F82 – 10 Amp Red Steering Column Control Module / Cruise Control
F83 – – Spare Fuse
F84 – 15 Amp Blue Switch Bank / Instrument Cluster
F85 – 10 Amp Red Airbag Module
F86 – 10 Amp Red Airbag Module
F87 – 10 Amp Red
Air Suspension – If Equipped / Trailer Tow / Steering
Column Control Module
F88 – 15 Amp Blue Instrument Panel Cluster
F90/F91 – 20 Amp Yellow Power Outlet (Rear Seats) Customer Selectable
F93 – 20 Amp Yellow Cigar Lighter - If Equipped
Cavity Cartridge Fuse Micro Fuse Description
8
