Whenever the Rear View Camera image is activated
through the ⬙Backup Camera⬙ button in the ⬙Controls⬙
menu, a display timer for the image is initiated. The image
will continue to be displayed until the display timer
exceeds 10 seconds and the vehicle speed is above 8 mph
(13 km/h) or the touchscreen button ⬙X⬙ to disable display
of the Rear View Camera image is pressed.
NOTE: If the vehicle speed remains below 8 mph
(13 km/h), the Rear View Camera image will be displayed
continuously until deactivated via the touchscreen
button ⬙X⬙.
If Equipped — Cargo Camera Icons:
•
— Backup Camera Touchscreen Button
•
— Cargo Camera Touchscreen Button
If equipped with a Cargo Camera, a touchscreen button
to indicate the current active Camera image being
displayed is made available whenever the Rear View
Camera image is displayed.
If equipped with a Cargo Camera, a touchscreen button
to switch the display to Cargo Camera image is made
available whenever the Rear View Camera image is
displayed.
A touchscreen button ⬙X⬙ to disable display of the camera
image is made available when the vehicle is not in RE-
VERSE gear.
When enabled, active guide lines are overlaid on the image
to illustrate the width of the vehicle and its projected
backup path based on the steering wheel position. The
active guide lines will show separate zones that will help
indicate the distance to the rear of the vehicle.
NOTE: For further information about how to access and
change the programmable features of the ParkView Rear
Backup Camera, refer to “Uconnect Settings” in “Multime-
dia” for further information.
The following table shows the approximate distances for
each zone:
Zones Distance To The Rear Of
The Vehicle
Red 0 - 1 ft (0 - 30 cm)
Yellow 1 ft - 6.5 ft (30 cm - 2m)
Green 6.5 ft or greater
(2 m or greater)
6
STARTING AND OPERATING 411
