Cavity Maxi Fuse Mini Fuse Description
F17 20 Amp Yellow Engine Control Module (ECM), Injectors (3.6
Gasoline Engine)
F17 20 Amp Yellow Secondary Loads, Engine Control Module (ECM)
(3.0 Diesel Engine)
F18 7.5 Amp Brown KL30 Engine Control Module (ECM), KL30 Main
Relay Coil (3.6 Gasoline Engine)
F18 7.5 Amp Brown KL30 Manual Transmission Automated (MTA),
KL30 Engine Control Module (ECM), KL30 Main
Relay Coil (3.0 Diesel Engine)
F19 7.5 Amp Brown A/C Compressor (If Equipped)
F20 30 Amp Green Windshield Wiper
F21 15 Amp Blue Fuel Pump
F22 20 Amp Yellow Engine Control Module (ECM), Ignition Coils (3.6
Gasoline Engine)
F22 20 Amp Yellow Engine Control Module (ECM), Primary Loads
(3.0 Diesel Engine)
