Cavity Maxi Fuse Mini Fuse Description
F23 20 Amp Yellow Electronic Stability Control (ESC) Valves
F24 7.5 Amp Brown KL15 Vacuum pump relay coil (3.6 Gasoline En-
gine) — If Equipped
F30 15 Amp Blue Heated Mirrors
Front PDC Additional Fuses
The additional fuse box is located inside the front PDC
Box.
Front Power Distribution Center Additional Fuses
366 MAINTAINING YOUR VEHICLE
