RAM RP500 - Dimensions and Versions; Physical Dimensions and Fitting Size; RP500 Available Versions

DIMENSIONS
Dim : 8U / 19”  483 x 355 x 75 mm
RP500 available in 3 versions:
 RP500 - 1: Mixing desk using standard faders / AES output.
(without MIDI card and USB option)
 RP500 - 2: Mixing desk using master faders / AES output.
(without MIDI card and USB option)
 RP500 - 3: Mixing desk using master faders / AES output / T Start MIDI controller and USB audio IN/OU
Fitting size :
445 mm x 348 mm
Console
Cut-out
483 mm
355 mm
445 mm
348 mm
483 mm
355 mm
345 mm
317 mm
38 mm
442 mm
75 mm
DIMENSIONS
RAmi
RP500
21
