Delay : 0 - 14,400 samples/0 - 300 ms (Fs = 48 kHz), 0 - 326 ms (Fs = 44.1 kHz)
Phase : normal/reverse (switchable)
Stereo meter : Bar graph type LED, Left and Right, 20 points for each
VU or PPM (selectable), Peak hold on/off, ∞
Fader : 100 mm motor fader ( x 21), +10 db - –90 dB –∞ dB
Display : LCD, 320 x 240 dot, with backlight
Memory : SCENE MEMORY (Snapshot) 50 registers
CHANNEL library 50 registers
EQUALIZER library 50 registers
DYNAMICS library 50 registers
AUTOMATION 4 mix
Ambient operating temperature : 0 °C - 40 °C (32 °F - 104 °F)
Dimensions (mm) : 698 (W) x 244 (H) x 549.5 (D)
Weight (without options) : 23kg (51lbs)
Finish : ABS resin (Top Panel), Blue black
Standard Accessories : Power Cord, Users’ Guide, Warranty Card, Registration Card
Dimensions and weights indicated are approximate.
Specifications are subject to change without notice.
Digital In and Out
2TR IN (INPUT 15,16) :
In/Out : In
Format : IEC 958 Professional (AES/EBU) or Consumer (S/PDIF) switchable
Level : RS-422 (AES/EBU) or 0.5 V [pp]/75 Ω (S/PDIF)
Connector : XLR 3-31
REC OUT :
In/Out : Out
Format : IEC 958 Professional (AES/EBU) or Consumer (S/PDIF) switchable
Level: RS-422 (AES/EBU) or 0.5 V[pp]/75 Ω (S/PDIF)
Connector : XLR 3-32
AUX RETURN 1/2 :
In/Out : In
Format : IEC 958 Consumer (S/PDIF)
Level : 0.5 V [pp]/75 Ω
Connector : RCA pin jack
Input Type Source Impedance Signal Level (Nominal-before clipping) Connector Type
CH input 1-8 5 kΩ mics, 50 Ω - 600 Ω –60 dB - –46 dB XLR 3-31 (bal)
lines, 600 Ω +10 dB - +24 dB XLR 3-31 (bal)
CH input 9-16 5 kΩ mics, 50 W - 600 Ω –60 dB - –46 dB TRS phone jack (bal)
lines, 600 Ω +10 dB - +24 dB TRS phone jack (bal)
CH Insertion Returns
1-16 10 kΩ lines, 600 Ω +4 dB - +18 dB TRS phone jack (unbal)
2TR B IN (analog) 10 kΩ lines, 600 Ω +4 dB - +18 dB TRS phone jack (bal)
AUX returns 3-6 10 kΩ lines, 600 Ω +4 dB - +18 dB TRS phone jack (unbal)
Input Type Output Impedance Adapted Load Impedance Signal Level (Nominal-before clipping) Connector Type
MASTER L/R 5 kΩ 150 Ω lines 600 Ω +4 dB - +18 dB XLR 3-32 (bal)
AUX sends 3 - 6 75 Ω lines 10 kΩ +4 dB - +18 dB TRS phone jack (unbal)
INSERTION 1 - 16 10 Ω lines 10 kΩ +4 dB - +18 dB TRS phone jack (unbal)
REC OUT L/R (analog) 150 Ω lines 10 kΩ +4 dB - +18 dB TRS phone jack (bal)
MONITOR A out L/R 150 Ω lines 600 Ω +4 dB - +18 dB TRS phone jack (bal)
MONITOR B out L/R 150 Ω lines 600 Ω +4 dB - +18 dB TRS phone jack (bal)
Headphones 8 Ω phones 40 Ω/8 Ω 400 mW/100mW Stereo phone jack (unbal)
Analog Inputs (0 dB = 0.775 Vrms, 0 dBV = 1 Vrms)
Analog Outputs (0 dB = 0.775 Vrms, 0 dBV = 1 Vrms)
