C1048 YF400104FZT Ceramic 0.1 µF
C1049 EEVHB1H100P Electrolytic 10 µF 50V
C1052 YF400104FZT Ceramic 0.1 µF
C1100 ECST1CY475R Plastic 47 µF 16V
C1101 ECST1CY105ZR Plastic 1 µF 16V
C1114,1116 ECKF1H102KB Ceramic 1000pF 5W
C1118,1121 ECKF1H102KB Ceramic 1000pF 5W
C1123 MCUV1H562KBN Ceramic 5600 pF 16V
C1126 YF400104FZT Ceramic 0.1 µF
C1127-1130 ECEVW1EA221P Electrolytic 220 µF 25V
C1131-1134 YWRVW1C470 Electrolytic 47 µF 16V
C1135 EEVHA1C221P Electrolytic 220 µF 16V
L143 YWBLM21B03PB Coil
L401 YWZBF503S01 Coil
L404,406 YWBLM21B03PB Coil
L408,410 YWBLM21B03PB Coil
L412,416 YWBLM21B03PB Coil
L418,420 YWBLM21B03PB Coil
L421-428 YWBLM21B03PB Coil
L501-508 YWBLM21A05PT Coil
L511-513 YWBLM21B03PB Coil
L653 YWBLM21B03PB Coil
L654-665 YWBLM21A05PT Coil
L668-674 YWBLM21B03PB Coil
L677,678 YWBLM21B03PB Coil
L683,800 YWBLM21B03PB Coil
L801 YWBLM21B03PB Coil
L802,901 YWBLM21A05PT Coil
L902-910 YWBLM21A05PT Coil
L1009 YWNL323R3J Coil 3.3 µH
L1010,1012 YWNL321R8J Coil 1.8 µH
L1014,1015 YWNL323R3J Coil 3.3 µH
L1016,1018 YWNL321R8J Coil 1.8 µH
L1020 YWNL323R3J Coil 3.3 µH
T901,902 YWPT1099 High Freq Transformer
CN33 YW520454010 40-pin Connector
CN52 YW521471310 13-pin Connector
CN53 YW521470710 7-pin Connector
CN54,55 YW521471510 15-pin Connector
CN58 YWB8BPHSM3TB 8-pin Connector
CN99 B10BPHSM3TB 10-pin Connector
CN501,502 YWNC3MBH1 Connector
JK503,504 YWYKB215261 Jack
JK651-656 YWYKB215261 Jack
JK901-904 YWYKB215261 Jack
JK905 YWYKC213924 Jack
M35 YWA3BA1039A4 Supporting Angle
M36 YWA2SA4485A4 Mounting Angle
REF. NO. PART NO. DESCRIPTION
95
PCB5 (RTL) YWR00DA7KYCA Printed Circuit Board Assy
D201-208 YWSML210VT86 LED
D209-226 YWSML210DT86 LED
D227 YWGL7H201 LED
D229-244 YWSML210MT86 LED
D245 YWSML210VT86 LED
D228 1SS353TE17 Diode
SW201 EVQPJS04K Push Switch
CN66 YW524921720 17-pin Connector
M23 YWA5XA0503A3 Reflection Plate
PCB6 (RTL) YWR0DA7GKYDA Printed Circuit Board Assy
IC301 YWBP5311 IC
IC302 YWCXAM10LL IC
R301 ERDS2TJ274 Carbon 270K ohms 1/4W
VR301 EVUF2AE35A55 Variable Resistor 500K ohms
C301 ECA1VM470 Electrolytic 47 µF 35V
C302 ECA1CM101 Electrolytic 100 µF 16V
C304 EXFP8102ZW Ceramic 1000 pF
Z301 EXBF9E473J Block Resistor
CN32 YW521511310 13-pin Connector
CN302 YW559712CPB Connector
E303 YWRDA7L67 Wire Assy for LCD unit
PCB7 (RTL) YWR00DA7KB8A Printed Circuit Board Assy
IC1 YWUPC4570G IC
IC21 YWUPC4570G IC
IC41 NJM4558MT3 IC
Q1,2 2SC4695TB Transistor
Q3,4 2SK374-RS Transistor
Q21,22 2SC4695TB Transistor
D41 YWMTZJ4.7BT77 Diode
D101 MA723 Diode
R1 YWR1220P472D Metal 4.7K ohms
R2 ERJ6GEYJ562 Carbon 5.6K ohms 1/10W
R4,5 YWR1220P103D Metal 10K ohms
R6 YWR1220P472D Metal 4.7K ohms
R8,9 YWR1220P473D Metal 47K ohms
R10 YWR1220P472D Metal 4.7K ohms
REF. NO. PART NO. DESCRIPTION
METER BOARD
INVERTER BOARD
MONITOR VR BOARD
To Next Page
