The VCO requires a very pure source of well-filtered DC, free of AC hum,
alternator whine or other disturbance. R19 and the 47 uf C40 form a basic
low pass filter. Transistor Q4 serves as an electronic capacitance multiplier.
The actual effect of the filter is that the beta of Q4 multiplies the 47 uf for a
virtual capacitance effect of a much larger device.
Stage G: The FX- Transceiver Synthesizer PLL
The MC145152 IC incorporates the equivalent of 8000
individual transistors and contains the following
circuits:
A crystal reference oscillator governed by Y2, 10.24 MHz.
A counter or "frequency divider" circuit set externally to divide the
crystal oscillator output by 2048, for a Reference Frequency output
of 5 KHz.
A second counter or frequency divider that divides the frequency
from the Prescaler (U3) by the externally programmed number that
we call "N".
A third frequency divider ("A") also used for programming
Control logic circuitry which permit the "N" and "A" counters to
work together for channel programming.
The Phase Detector (or "phase corrector") which compares the 5
KHz Reference Frequency with the "intended" 5 KHz output of the
N-divider and sends correcting pulses to the VCO to keep the
output of the N-divider right at 5 KHz.
A "lock detect signal" circuit. The reference oscillator is internal to
U6, governed by Y2.
The precision of the 10.240 MHz reference oscillator can be adjusted by
trimmer C81. The R divider feeds 5 KHz to the phase detector section of U6
(10240 KHz divided by 2048).
The output of the UPB569, Ã64/65 prescaler U3 is AC coupled via C57 to
pin 1. U3 is a dual modulus prescaler, controlled by pin 9 of U6. The
prescaled output of the VCO is fed to the A and N counters. The "N" number
programmed on the diode matrix is predetermined to divide this frequency
down to 5 KHz for phase comparison with the 5 KHz output of the crystal
controlled reference divider. Maximum "N" is 65,535, achieved by switching
FREQ. N = BINARY PROGRAMMING VALUES
222.000 44,400
225.000 29,600
1010 1101 0111 0000
1010 1111 1100 1000
223500 (KHz)
5 (KHz)
