Ramsey Electronics FX Series - Page 28

FX-223 Quick Program Reference
Standard 220 MHz band repeater pairs and selected frequencies
Program as follows:
1. Install diodes at 16K, 8K, 4K and NO diodes at 32K, 2K ,1K positions.
2. PLUS install diodes at 512 through 1 positions as needed per this Quick
Reference Chart.
3. For repeater channels, add the proper repeater TX offset diode.
Simplex channels: add the 'SIMP' diode.
4. A '1' means to install a diode, '0' means NO diode.
Frequency N 512 256 128 64 32 16 8 4 2 1
223.92 44,784 1 0 1 1 1 1 0 0 0 0
223.94 44,788 1 0 1 1 1 1 0 1 0 0
223.96 44,792 1 0 1 1 1 1 1 0 0 0
223.98 44,796 1 0 1 1 1 1 1 1 0 0
224.00 44,800 1 1 0 0 0 0 0 0 0 0
224.02 44,804 1 1 0 0 0 0 0 1 0 0
224.04 44,808 1 1 0 0 0 0 1 0 0 0
224.06 44,812 1 1 0 0 0 0 1 1 0 0
224.08 44,816 1 1 0 0 0 1 0 0 0 0
224.10 44,820 1 1 0 0 0 1 0 1 0 0
224.12 44,824 1 1 0 0 0 1 1 0 0 0
224.14 44,828 1 1 0 0 0 1 1 1 0 0
224.16 44,832 1 1 0 0 1 0 0 0 0 0
224.18 44,836 1 1 0 0 1 0 0 1 0 0
224.20 44,840 1 1 0 0 1 0 1 0 0 0
224.22 44,844 1 1 0 0 1 0 1 1 0 0
224.24 44,848 1 1 0 0 1 1 0 0 0 0
224.26 44,852 1 1 0 0 1 1 0 1 0 0
224.28 44,856 1 1 0 0 1 1 1 0 0 0
224.30 44,860 1 1 0 0 1 1 1 1 0 0
224.32 44,864 1 1 0 1 0 0 0 0 0 0
