Ramsey Winch DC 34,9 - User Manual

Questions and Answers

K
Kimberly RosarioAug 15, 2025
Why does my Ramsey Winches motor run, but with insufficient power or low line speed?
- S
  Stephen RobertsAug 15, 2025
  Several factors can cause a Ramsey Winches motor to run with insufficient power or low line speed: * Insufficient battery: Check the battery terminal voltage under load. If it's 10 volts or less, replace the battery or connect another battery in parallel at the motor terminal. * Undersized electrical cables: Ensure you're using the correct gauge wire. Use #2 gauge wire for distances up to 4,5 m (15 ft) from the battery to the winch. For longer distances, use a larger gauge. * Poor electrical connections: Inspect all connections for looseness or corrosion. Tighten, clean, and grease them. * Insufficient charging system: Consider replacing your current system with a larger capacity charging system.
T
Tina HunterAug 21, 2025
Why does my Ramsey Winches motor run extremely hot?
- J
  James MaldonadoAug 22, 2025
  If your Ramsey Winches motor runs extremely hot, it may be due to prolonged operation. Cooling-off periods are essential to prevent overheating.
A
andrewkingAug 25, 2025
What to do if my Ramsey Winches motor runs, but the drum doesn't turn?
- D
  danielharrisAug 26, 2025
  If the motor runs but the Ramsey Winches drum does not turn, and the clutch is engaged, it will be necessary to disassemble the winch to determine the cause and repair. Possible causes include: * Clutch not engaged * Sheared drum shaft key * Stripped bronze gear * Parted shaft
S
Susan StricklandAug 28, 2025
What causes oil leaks from the housing of my Ramsey Winches?
- D
  Daniel RitterAug 28, 2025
  Oil leaks from the housing of your Ramsey Winches can be caused by: * A damaged or worn seal: Replace the seal. * Too much oil: Drain the excess oil. Refer to TECHNIQUES OF OPERATION. * A damaged gasket: Replace the gasket.
H
hunterjustinAug 31, 2025
How to fix a clutch that is inoperative or binds up on my Ramsey Winches?
- J
  Joshua MooreAug 31, 2025
  If the clutch on your Ramsey Winches is inoperative or binds up: * Dry or rusted shaft: Clean and lubricate it. * Bent yoke or linkage: Replace the yoke or shaft assembly. * Clutch jaws in contact: See TECHNIQUES OF OPERATION.
K
Kristen WellsSep 4, 2025
What to do if my Ramsey Winches cable drum will not free spool?
- C
  collinsvanessaSep 4, 2025
  If your Ramsey Winches cable drum won't free spool, it might be because the winch isn't mounted squarely, causing the end bearings to bind the drum. Check the mounting. Refer to WINCH MOUNTING Page 5.
E
Edward BaileySep 7, 2025
Why does my Ramsey Winches cable bird nests when the clutch is disengaged?
- R
  Robert PalmerSep 7, 2025
  Cable bird nesting in your Ramsey Winches when the clutch is disengaged is often due to a worn drag brake disc. Replace the discs.
C
Caroline StewartSep 10, 2025
Why does my Ramsey Winches motor run in one direction only?
- W
  waguilarSep 12, 2025
  If your Ramsey Winches motor only runs in one direction, the issue could be: * A faulty or stuck solenoid: Try jarring the solenoid to free the contacts. Test it by applying 12 volts to the coil terminal; it should click when energized. * A malfunctioning switch: Disengage the winch clutch or remove the armature lead. Remove the switch plug from the hood, raise the connector cover, and short the bottom two pins with a screwdriver. The solenoid should click. Short the two left-hand pins; the other solenoid should operate. If both solenoids operate, check for a broken wire in the switch cable. * A broken wire or poor connection: Check for loose connections on the switch and switch connector.
R
Raymond McconnellNov 17, 2025
What to do if my Ramsey Winches motor will not operate?
- K
  Karen WestNov 17, 2025
  If your Ramsey Winches motor isn't operating, here's what you can check: * Solenoid issues: Try jarring the solenoid to free the contacts. Test the solenoid by applying 12 volts to the coil terminal; you should hear an audible click when it's energized. * Switch problems: Check the switch. You can disengage the winch clutch or remove the armature lead, then remove the switch plug from the hood. Raise the connector cover on the hood and use a screwdriver to short the bottom two pins. The solenoid should click. Short the two left pins; the other solenoid should operate. If both solenoids work, inspect the switch cable for broken wires. * Motor failure: If the solenoids are functioning, check for voltage at the armature post. If there's no voltage, replace the motor. * Loose connecti...
