The machines in the EPOCA series have been desi-
gned to prepare express coffee and hot beverages.
A positive-displacement pump inside the machine
powers the heater in which the water is heated. By
pressing the appropriate buttons, water is supplied
to the spouts in the form of hot water or steam, ac-
cording to needs.
The water to be used for the beverages is supplied
directly by the water supply, pressurized by the pump
and immediately heated by the steam produced by
the boiler.
The machine is composed of a steel carrying struc-
ture on which the mechanical and electrical compo-
nents are tted. These are completely covered with
panels made of painted polyurethane and stainless
steel.
The beverages are dispensed at the front of the
machine, where all the buttons, control devices and
dispensers are to be found.
There is a cup-warming plate on the top of the ma-
chine.
Legend:
A Semiautomatic system; manual dispensing start
and stop.
B Automatic system; electronic control of coffee
and hot water doses dispensed.
C N. of coffee dispensing units.
N. of steam spouts.
E N. of hot water spouts.
On request:
● cup-warmer.
1 Steam tap
2 Steam spout
3 Hot water tap
4 Hot water spout
5 Coffee dispensing unit
6 Coffee dispensing button
7 Manual water supply tap
8 Level indicator
9 Gauge
10 Power on-off switch and led
11 Switch and boiler resistance engagement light.
12 Cup heater switch and indicator
A B C E
E - ok 2 2 1
S ok - 2 2 1
The machine is equipped with the following protective
devices:
● complete panelling protection of all the parts
subject to heat and of the steam and hot water
supplier;
● cup-warmer plate supplied with a tray to collect
spilt liquids;
● work surface provided with grill and tray to collect
spilt liquids;
● expansion valve in the hydraulic system and valve
on the boiler to avoid overpressure;
● nonreturn valve on the hydraulic system to avoid
owing back to the main supply.
1
2
Filters 3
1
1
1
1
Pipe connections 1
1
Instruction manual 1
Brush 1
1
