6
2.2. Machine equipment
2 GROUP
1 dose filter holder
1
2 dose filter holder
2
Filters
3
Blind filter for backflushing
1
1 mt. supply pipe
1
1,5 mt. supply pipe
1
1,5 mt. drainage pipe
1
Supply pipe adapters
1
Blind disks for cleaning
2
Doser and tamper
1
Instruction manual
1
Wiring diagram
1
2.3. Mechanical protective devices
The machine is equipped with the following
protective devices:
· Complete paneling protection of all the parts
subject to heat; and of the steam and hot water
supplier.
· Cup-warmer plate supplied with a tray to collect
drips of water from freshly washed cups.
· Work surface with grill and tray to collect
spilled liquids.
· Expansion valve in the hydraulic system and
valve on to boiler to avoid overpressure.
· Anti-siphon valve on the hydraulic system to
avoid backflow to the main supply.
2.4. Power safety devices
The safety devices provided are:
· 5V low tension push buttons on the DE control
key panel.
· Thermal protection on the pump motor.
· High limit for element protection.
2.5. Aerial noise
Noise level in the working place does not usually
exceed 70dB(A).
2.6. Vibrations
The machine is supplied with rubber vibration
dampening feet. In normal working conditions,
the machine does not produce vibrations
harmful to the operator or the equipment.
3. TECHNICAL DATA
3.1. Dimensions and weights
2
GROUP
A
31"
B
30"
C
22"
D
16"
H
19"
Boiler capacity in liters
11
Machine weight lbs
121
Water inlet (BSPT)
3/8"
Ømm drainage
14
Packaging
Volume
13
Dimensions W x D x H
35x27x28
Gross weight lbs
148
