Table 11. Hoist Body Parts List
ITEM PART NUMBER DESCRIPTION QTY
52292290 TWO SPEED BODY & CONTROLS: 208/230V – 3 PHASE 1
52292289 TWO SPEED BODY & CONTROLS: 460V – 3 PHASE 1
52292291 TWO SPEED BODY & CONTROLS: 575V – 3 PHASE 1
52315417 SINGLE SPEED BODY & CONTROLS: 115V – 1 PHASE 1
1 N/A MACHINED HOIST BODY WITH STATOR 1
2 2218060 TOP HOOK SET 1
2a 2212016 TOP HOOK SAFETY LATCH – STEEL PLATE TYPE 1
2b 52299408 COUPLING SET 1
3 2218055 MOTOR END CAP ASSEMBLY 1
5 2218056 BRAKE COVER SET 1
6 2218057 GEAR COVER / FLANGE ASSEMBLY 1
7 2218000 PUSH BUTTON ANCHOR ASSEMBLY 1
8 2218004 POWER CABLE GUIDE 1
9 2218058 GASKET SET 1
10 2406879007
LM1 BRANDING SET
1
12a 2213309005 BODY CAPACITY STICKER - 1/8 TON 1
12b 2213309001 BODY CAPACITY STICKER - 1/4 TON 1
12c 2213309018 BODY CAPACITY STICKER - 125 KG 1
12d 2213309007 BODY CAPACITY STICKER – 250 KG 1
- 2213445002 ELECTRICAL HAZARD WARNING SIGN 1
- 2213445001 ELECTRICAL WIRING INFORMATION LABEL 1
- 52296703 2-FALL WARNING LABEL (2-FALL ONLY) 1
