Tab
le 12. Helical Gear Mechanism and Brake Parts List
ITEM PART NUMBER DESCRIPTION QTY
1a 2218040 ROTOR ASSEMBLY – 3 PHASE POWER SUPPLY
1
1b 52315094 ROTOR ASSEMBLY – 1 PHASE POWER SUPPLY
1
2 2218041 CHAIN SPROCKET ASSEMBLY
1
3 2218042 FRICTION DISC ASSEMBLY FOR SLIP CLUTCH
1
3a 52253656 SLIP CLUTCH FRICTION DISC
1
4 2218043 GEAR ASSEMBLY
1
5a 2218030 MOTOR BRAKE ASSY 190 VDC – 460 VAC
1
5b 2218031 MOTOR BRAKE ASSY 100 VDC – 115/208/230 VAC
1
5c 2218032 MOTOR BRAKE ASSY 230 VDC – 575 VAC
1
6 2218044 SLIP CLUTCH SPRING SET
1
7,8,9 52309505 BEARING SET (7 TOTAL PER SET)
1
