TABLE OF CONTENTS
R&R SOUND AMPLIFICATION SL/LD MultiGain PRE-AMPLIFIER
MANUAL
1-1
R&R SL/LD MultiGain PRE-AMPLIFIER. OVERVIEW
PRECAUTIONARY MEASURES
FRONT PANEL CONTROLS
џ turn on / turn off
џ channel CLEAN CH-1
џ channels LEAD CH-2 и CH-3
BACK PANEL CONTROLS
џ network connection, input / outputs
џ FX LOOP
џ modes BRIGHT / NORMAL second channel
џ modes A250K / A1M third channel
џ external preamp control
џ type, location and purpose of lamps
WIRING SCHEMES
PREAMPLIFIER ELECTRICAL BLOCK SCHEMES
SPECIFICATIONS
EXAMPLES OF FACTORY PRESETS
џ channel setting CH-1 CLEAN
џ channel setting CH-2 LEAD-1
џ channel setting CH-3 LEAD-2
1-2
1-4
2-1
2-1
2-1
2-2
3-1
3-1
3-1
3-2
3-2
3-2
3-2
4-1
4-2
4-3
5-1
5-1
5-2
5-3
