R&R Ampflication SL - Front Panel Controls; Turn on; Turn off; Channel CLEAN

1
2
3
CH-3
LEAD-2
LEAD-1
MASTER
ROUND
EDGE
OFF
R&R SOUND AMPLIFICATION SL/LD MultiGain PRE-AMPLIFIER
MANUAL
2-1
FRONT PANEL CONTROLS
turn on / turn off
channel CLEAN CH-1
CLEAN LED
Green indicator of activity of the
first channel (CLEAN CH-1).
6
BASS
Control of the amount of low
frequencies in the signal for the
first channel.
CLEAN / LEAD
Select whether the CLEAN channel
(CH-1) or LEAD channels (CH-2
and CH-3) are active.
7
POWER ROUND/OFF/EDGE
Modes:
ROUND - more viscous,
compressed sound.
POWER LED
Red glow power indicator.
MASTER
Output level control (setting the
overall signal level for the three
channels).
1
2
3
OFF - turned off.
EDGE - sharper, sharper sound.
2
4
3 5
6 7
INPUT
GAIN
TREBLE
MID
BASS
CH-1
LEAD
CLEAN
1
INPUT
Instrument input for connecting a
guitar.
1
5
GAIN
Control of the overall gain and
sensitivity of the first channel.
2
TREBLE
Control of the amount of high
frequencies in the signal for the
first channel.
3
MID
Control of the number of mid
frequencies in the signal for the
first channel.
4
