R&R Ampflication SL - Channels LEAD CH-2 И

BASS
Controls the amount of low
frequencies in the signal for the
second channel LEAD-1 CH-2 and
the third channel LEAD-2 CH-3,
respectively.
2-2
R&R SOUND AMPLIFICATION SL/LD MultiGain PRE-AMPLIFIER
MANUAL
channels LEAD CH-2 и CH-3
18 19
110
111 112
113
11
161514131211
114
11115
17
1
GAIN
Controls the overall gain and
sensitivity of the second channel
LEAD-1 CH-2 and the third
channel LEAD-2 CH-3
respectively.
TREBLE
Controls the amount of high
frequencies in the signal for the
second channel LEAD-1 CH-2 and
the third channel LEAD-2 CH-3
respectively.
2
9
10
MID
Controls the amount of mid
frequencies in the signal for the
second channel LEAD-1 CH-2 and
the third channel LEAD-2 CH-3,
respectively.
3
11
4
PRESENCE
Transparency control for the
second channel LEAD-1 CH-2 and
the third channel LEAD-2 CH-3
respectively. Allows you to control
higher frequencies than the
TREBLE control.
5
12
13
MASTER
Master volume for the second
channel LEAD-1 CH-2 and the
third channel LEAD-2 CH-3
respectively.
6
14
LEAD-1 / LEAD-2 (CH-2/CH-3)
Selects the activity of the LEAD-1
CH-2 channel and the LEAD-2
CH-3 channel.
4
“LEAD-1” LED
Blue glow indicator of activity of
the second channel LEAD-1 CH-2.
8
“LEAD-2” LED
Indicator of red glow of activity of
the third channel LEAD-2 CH-3.
15
GAIN
LEAD
CLEAN
MIDTREBLE PRESENCE
BASS
MASTER
CH-3
LEAD-2
LEAD-1
CH-2
MA
FRONT PANEL CONTROLS
