RANE SL2 FOR SERATO SCRATCH LIVE • OPERATOR’S MANUAL 2.4.4
SL2 Specifications
CODEC 24-bit PCM
44.1 kHz Sample Rate Frequency
Response
-0.5 dB @ 20 Hz, -1.22 dB @ 20 kHz
48 kHz Sample Rate Frequency Response -0.5 dB @ 20 Hz, -0.40 dB @ 20 kHz
Sample Rate Selection 44.1 / 48 kHz selected in software control
panel
Deck Inputs Unbalanced RCA with CD / Phono switch
……Phono Maximum Input 70 mV rms @ 1 kHz
……Phono Gain 33 dB at 1.0 kHz
……Line Level (CD) Maximum Input 3 Vrms
Line Outputs: Unbalanced RCA
…...THD+N 0.007% @ 1 kHz
…...Maximum Output 3 Vrms
…...Dynamic Range 101 dB A-weighted analog in to analog out
Dynamic Range DAC 104.5 dB A-weighted
Device Latency 1.4 ms @ 44.1 kHz and 1.3 ms @ 48 kHz
USB 2.0 High Speed Port Required 3-unit load (300 mA max)
Blue Indicator Flashing while device is booting
Lit when USB 2.0 connection is detected
Yellow Indicator Lit when the analog section is powered on
Optional RS5 External Universal Power
Pack
7.5 Volts DC, P6 barrel plug
Power: Turn On/Off Muting Yes
…...Galvanic Isolation: Audio I/O is actively isolated from USB port and external power
…...Auto-selects USB or external power without interruption
SL2 Unit: Size 5.5˝ x 5˝ x 1.3˝ (14.1 x 12.5 x 3.3 cm)
Shipping: Size 14˝ x 14˝ x 4˝ (36 x 36 x 10 cm)
……Weight
5 pounds (2 kg)
