Range Master 52916 - Step 3 & 4: Supports, Wheels, and Bowl Mounting

11
Assemblyinstrucons
STEP 3
InstalltheLeLegSupport(6)ontolegs(2)and(4)usingM6*42Screws(A)andM6
FlangeNuts(B).InstalltheRightLegSupport(31)usingthesamehardwareastheLe
LegSupport.DonotghtenscrewsunlStep5iscompleted.
InsertAxle(8)throughtheholesattheboomoflegs(1)and(3).PuttheWheels(7)on
theendsoftheAxle.ThreadM10LockNuts(K)ontoeachendoftheAxleandghten
withWrench(O).
STEP 4
PuttheBowl(9)ontopofthelegs.Note
thattheholesforthehingesshouldbe
atthebackofthegrill.
AssembletheFrontShelfSupportPiece
(10)andtheBowl(9)throughlegs(3)
and(4)usingM6*42Screws(A)andM6
FlangeNuts(B).
AssembletheBowl(9)throughlegs(1)
and(2)usingM6*42Screws(A)andM6
FlangeNuts(B).
