3.2. LED Display
3.2.1. 5-band amplification system
Applies to models Spear 300 PRO, Spear 1000 PRO
1 – 5 bars of the output signal strength indicator, which show
you the maximum output power of the repeater. Each signal bar
represents 5dB.
4 – Antenna Isolation Detection. When the repeater is first
powered up, the repeater will detect the oscillation
automatically between the outdoor antenna and indoor
antenna.
5 – Uplink Sleep Mode. The uplink of the repeater is in standby
mode when there is no call or data transmission. It will activate
immediately when a call/data session is initiated.
2 – The specific value of the input signal strength measured in
dBm, tells the exact input signal level.
3 – Shows the UL&DL central frequency of the supporting
system.
6 – Shows the UL maximum gain.
7 – Shows the DL maximum gain.
