DIMENSIONS FOR RBC38 GLASS DOOR
7
857 to 883mm
Rough In Opening Dimensions, for RBC38 Glass Door
381mm
*610mm
* Depth dimension may vary depending on
each individual installation.
876mm
Electrical Requirements: 230 volts, 1.7 amps
running max. A three pin earthed receptacle is
required.
Power outlet can be located in the back wall
behind unit. Add 19mm to depth for thickness of
plug, or recess outlet 19mm into the wall. Power
outlet can also be installed in adjacent cabinetry
with a cutout for routing of power cord. Follow
all local building codes when installing electrical
and unit.
Product weight = 39kg
375mm
76 to 102mm
538mm
578mm
627mm
927mm
419mm
Electrical-voltage/frequency 220-240 V / 50Hz
Energy efficiency class on a scale
of A (more efficient) to G (less efficient)
A
Climate class
(SN=10-32°C,
N=16-32°C, ST=18-38°C, T=18-43°C
T
Temperature range
(from > to) 4.4 to 18.3°C
Gross capacity 85 litres
Net capacity (4) 750ml bottles
/(72) 330ml cans
Energy consumption/year 135 kWh/yr
Energy consumption (EN153) 0.37 kWh/24 hrs
Max noise level 48 db(A)
Ratings
INSTALLER: Please leave these instructions with the user.
DATA BADGE LOCATION: Front left-hand side of the
refrigerator compartment.
COUNTRY OF DESTINATION: GB/IE
