7
DIMENSIONS FOR RWS60
Rough In Opening Dimensions for RWS60
610mm
*610mm
* Depth dimension may vary depending on
each individual installation.
876mm
Electrical Requirements: 230 volts, 1.7 amps
running max. A three pin earthed receptacle
required.
Power outlet can be located in the back wall
behind unit. Add 19mm to depth for thickness of
plug, or recess outlet 19mm into the wall. Power
outlet can also be installed in adjacent cabinetry
with a cutout for routing of power cord. Follow
all local building codes when installing electrical
and unit.
Product weight = 54 kg
607mm
76 to 102mm
559mm
857 to 883mm
599mm
1179mm
648mm
651mm
Electrical-voltage/frequency 220-240 V / 50Hz
Energy efficiency class
on a scale of
A (more efficient) to G (less efficient)
B
Climate class (SN=10-32°C,
N=16-32°C, ST=18-38°C, T=18-43°C
T
Temperature range
(from > to) 4.4 to 18.3°C
Gross capacity 175 litres
Net capacity 45 bottles
Energy consumption/year 184 kWh/yr
Energy consumption (EN153) 0.50 kWh/24 hrs
Max noise level 50 db(A)
Ratings
INSTALLER: Please leave these instructions with the user.
DATA BADGE LOCATION: Front left-hand side of the
refrigerator compartment.
COUNTRY OF DESTINATION: GB/IE
