Rans Inc. Section 6
Model S-7LS COURIER Normal Procedures
Original Issue March 3, 2005 6- 12
NOTE: For more specific information regarding powerplant operation, refer to the Rotax
Operator's Manual. The manual contains IMPORTANT safety, maintenance, and
operating information.
TAXING (Ground Handling)
The S-7LS is a tail wheel aircraft. Concentrate on taxiing till the moment you tied the
aircraft down.
When taxing, it is important that speed and use of brakes is held to a minimum and that
all controls are utilized to maintain directional control and balance as shown in Fig. 6-2.
Figure 6-2. Taxiing Diagram
The arrows identify the wind direction. It is very important to hold the controls as
described, even when the aircraft is not moving.
USE UP AILERON
ON RH WING
AND UP ELEVATOR
USE DOWN AILERON
ON RH WING
AND DOWN ELEVATOR
USE DOWN AILERON
ON LH WING
AND DOWN ELEVATOR
USE UP AILERON
ON LH WING
AND UP ELEVATOR
To Next Page
