Raritan Dominion KX II User Manual

Chapter 8: Device Management
215
Modifying Scripts
To modify existing scripts:
1. Click Device Settings > Connection Scripts. The Connection Scripts
page opens.
2. In the Available Connection Scripts section, select the script you
want to modify and click Modify. The page is then in Edit mode.
3. Make changes as needed. Click OK when finished.
Importing and Exporting Scripts
You are able to import and export connect and disconnect scripts that
are in XML file format. Keyboard macros cannot be imported or exported.
Note: The import and export feature is not available from the Local
Console.
Imported scripts can be edited in KX II using the Modify feature. However,
once an imported script is associated with a port, it cannot be modified.
Remove the script from the port to modify it. See Applying and
Removing Scripts (on page 211).
To import a script:
1. Click Device Settings > Connection Scripts. The Connection Scripts
page opens.
2. In the Available Connection Scripts section, click Import. The Import
Connection Scripts page opens.
3. Select the import setting.
 Skip duplicates - Scripts that already exist in KX II are not
included in the import.
 Overwrite duplicates - Scripts that already exists in KX II are
overwritten by the new, imported script.
 Add duplicates with a different name - Duplicate scripts will be
renamed during the import and will not overwrite existing scripts.
KX II assigns a number to the file name to distinguish it from the
original.
4. Use the browse function to locate the XML script files to import.

Raritan Dominion KX II Specifications

General

Model	Dominion KX II
Category	KVM Switch
Local Console Ports	1
Video Resolution	Up to 1920 x 1200
Maximum Resolution	1920 x 1200
Network Interface	10/100/1000 Mbps Ethernet
Audio Support	Yes
Form Factor	1U Rackmount
On-Screen Display (OSD)	Yes
Power over Ethernet (PoE)	No
Ports	16, 32
Video Support	VGA, DVI, HDMI
USB Support	Yes
Security Features	SSL
Encryption	AES
Authentication	RADIUS, LDAP, Active Directory
Remote Access	Yes
Operating Temperature	0°C to 40°C (32°F to 104°F)
Storage Temperature	-20°C to 60°C (-4°F to 140°F)
Humidity	10% to 90% (non-condensing)
Number of Users Supported	Up to 64 concurrent users
