Ravaglioli KP442 E DUO User Manual

62
0626-M003-1
Distanza all'origine mm 15
Distance at origin 15 mm
Abstand neu 15 mm
Distance à l’origine mm 15
Distancia al origen 15 mm
Alla massima usura mm 13
At maximum wear 13 mm
Abstand bei max. Abnutzung 13 mm
A l’usure maximale mm 13
Al máximo desgaste 13 mm
18
19
8
• COLONNA COMANDI
• CONTROL COLUMN
•COLONNE DES COMMANDES
• STEUER-SÄULE
• COLUMNA MANDOS
SALITA
RISE
HEBEN
MONTÉE
ELEVACIÓN
SALITA
RISE
HEBEN
MONTÉE
ELEVACIÓN
R = Destra - Right
1
3
2
4
13 mm
15 mm
5
6
7
