22
KPX 336-337 W-WK-WR
0472-M002-3
1
4000
1500
KPX 336 - KPX 337 = 2500
KPX 336 1600 Kg 1.300.000 Kgmm 200.000 Kgmm
KPX 337 1900 Kg 1.500.000 Kgmm 300.000 Kgmm
6
P Mx My
