12 0700-M010-0 RAV4300 A3
Fig. 5A
RAV4800
RAV4650
3
511
350
148
250
(1031)
190
190
160
20
N°2 Fori Ø 7 (solo ponti SI)
N. 2 holes Ø 7 (on SI lifts only)
N° 2 Bohrungen Ø 7 (nur Hebebühnen SI)
N° 2 Orifices Ø 7 (uniquement ponts SI)
N. 2 Agujeros Ø7 (sólo puentes SI)
N°8 Fori Ø 7 Passanti
N. 8 through holes Ø 7
8 durchgehende Bohrungen Ø 7
N° 8 Orifices Ø 7 Passants
N. 8 Agujeros Ø7 pasantes
456
350 148 250 (1346)
160
20
N°8 Fori Ø 7 Passanti
N. 8 through holes Ø 7
8 durchgehende Bohrungen Ø 7
N° 8 Orifices Ø 7 Passants
N. 8 Agujeros Ø7 pasantes
RAV4300, 4350, 4350A, 4351, 4351T, 4352, 4355,
4356, 4400, 4401, 4401 BMW, 4401T, 4402, 4402 BMW,
4405, 4406, 4501, 4501L, 4502, 4250, 4250N, 4251,
4251N, 4252, 4252N, 420, 420N, 421, 421N, 421NS,
422, 422N, 424, 4210SI, 4210NSI, 4212SI, 4212NSI,
4251SI, 4251NSI, 4252SI, 4252NSI, 4252NSIAU
