Ravas RCS - 7.6 System Wiring Connections

17
.
It is recommended that the installation of the system is executed by an
official forklift truck dealer.
For the best accuracy the mast, rollers and bearings should be in good
condition:
.
Make sure there is no pressure on hydraulic system before
working on hydraulic system
Product overview:
1. Indicator mounting
support
2. Indicator (display)
unit
3. T-piece (supplied by
installer)
4. Sensor
5. Sensor cable
7. Reverence level
stickers.
Support the forks and
make sure that the chain
in the mast is loose and
no pressure remains in
the s
y
stem.
