6 RBR Enterprise Vector 300 LS/Venturi LS SmarTrax™ Installation Manual
Bracket - Hydraulic Valve Mounting 107-0171-907 1
Cable - Node Harness 115-4001-173 1
Cable - Valve Harness 115-4001-174 1
Assembly - SmarTrax Enable Foot Switch 063-0172-470 1
Bolt - 5/16”-18 x 7/8” Hex 311-0052-104 4
Bolt - 3/8”-16 UNC x 1/4” Hex 311-0054-106 1
Nut - 3/8”-16 UNC-3B Nylon Insert Lock 312-4000-061 1
Washer - 5/16” Split Lock 313-1000-019 4
Washer - 3/8” Flat 313-2300-013 2
TABLE 1. SmarTrax Installation Kit (P/N 117-5030-010)
Picture Item Description Part Number Qty.
