FLUECLEANING
COOKER
When burn,

coke, anthracite or other smokeless fuel, the flue should be cleaned
once a month . The use of coal may call fqr weekly cleaning . The procedure is
illustrated in Figs . 3,4and 5 .
Allow the fire to bum out, or it may be done with slow fire
.
Open
the
chimney
damper to its maximum . Remove the
flue
chamber cleaninS door . Brush
the
soot
from
the flue pipe,
letting it fail onto
the
top of the
oven
.
Remove
the phg from
the hot plate, rake the soot forward, and push it
into
the firebox (Fig . 5) . Replace
parts removed .
Riddle the bottom grate thoroughly, dear the aahpit sad redght the fire .
CHIMNEY
Ensure the chimney flues are thoroughly swept
at
12 monthly intervals . inspect
any soot box at the base of the chimney every
3
months
sad
remove any
accumulation of
deposit
.
CLEANING THE ENAMEL
Surface blemishes caused by spillage are easier to remove when the cooker is Cool,
and a damp cloth is usually
all
that is necessary . This should not be done whilst
the cooker is hot .
THE WARMING OVEN (Royal only)
This oven is primarily intended for heating plates and keeping food wart .
NOTE
Take care when dosing the oven and fire doors to lift them on to the catch . The
doors should not be slammed shut, or this will wear away the metal retainer
catches
REMOVAL OF BOILER FOR CLEANING
(Instructions for Heating Engineers)
Turn dff the water from the main and drain the system . Disconnect
flow and
return pipes, and withdraw boiler through side of the cooker inspection panel,
and take out the insulating material on top and behind boiler . After replacing
boiler, repack the insulating material above and behind the boiler . Make good
with fire cement the joints between boiler and fire bricks . Re-make all pipe joints .
FIREBRICK REPLACEMENT
The firebricks fitted to 'Rayburn' Royal and Regent Cookers are of first quality
manufacture, and providing the cooker has been installed and used correctly
will have
a
reasonable life . They
are,
however, expendable items and in time will
require renewal .
The renewal of firebricks is not a major operation and can be carried out by
the average handyman . Replacement bricks either in sets or singly can be
obtained from your 'Rayburn' distributor . The bottom three bricks can be
removed and replaced without disturbing the remainder of the set . Always
quote the manufacturing number .
The Manufactureing number,
which will be found on
a
brass plate inside the
Roasting Oven, should be quoted if
any question arises in connection with the
Rayburn Cooker .
With Rayburn's policy of continuous product Improvement . the Company reserves the right to change
epeellkatione and make modtlcatbne to the appliance deeabed and Illustrated at any time .
PO Box 30 Kefley Telford Shropshire TF14DD
Telephone (0952) 641100 Telex 35196 Fax
(0952) 641961
RLFIA 8189 (3) EWKO 33594
