Wuhan Raycus Fiber Laser Technologies Co., Ltd.
User Guide of RFL-C3300W~RFL-C15000W
12
Figure 4-a Front and rear view of the laser
Figure 4-b Top and left view of the laser.
Figure 4 The dimensions of RFL-C15000 continuous wave fiber laser.
The type and dimensions of RFL-C3300X / C4000X / C6000X / C8000X /
C10000X / C12000X / C15000 continuous fiber laser output cable and output
cable head are as follows:
(1) RFL-C3300X / RFL-C4000X / RFL-C6000X lasers use RFL-HQBH output
optical cable, and the dimension of output optical cable head are shown in
Figure 5;
Figure 5 RFL-QBH output optical cable head
