8.1Waypoints
Awaypointisapositionmarkedonthescreentoindicateasite
oraplacetonavigateto.
Aswellasactingaspositionmarkers,waypointsarealsothe
buildingblocksusedtocreateroutes.
Commonwaypointfunctionsareaccessedusingthewaypoints
menu.ThiscanbeshownatanytimebypressingtheWPTbutton.
Waypointdisplayexamples
Waypointsinthechartapplication
Inthechartapplicationbothactiveandinactivewaypointsare
shown.Theactivewaypoint(i.e.theoneyouareheadingtowards)
hastheboxandsymbolcolorsreversed.
D
117 61-2
1
2
3
ItemDescription
1Inactivewaypoint
2Activewaypoint
3Alternativewaypointsymbols
Bydefault,allwaypointsareindicatedonscreenbyawaypoint
symbol(x).Youcanassigndifferentsymbolsifrequired,orchoose
whichwaypointsareshown.
Waypointsintheradarapplication
Intheradarapplicationbothactiveandinactivewaypointsare
shown.Theactivewaypoint(i.e.theoneyouareheadingtowards)
hastheboxandsymbolcolorsreversed.
D
117 59-2
Bydefault,allwaypointsareindicatedonscreenbyawaypoint
symbol(x).Youcanassigndifferentsymbolsifrequired,orchoose
whichwaypointsareshown.
Waypointsintheshnderapplication
Waypointsintheshnderapplicationarerepresentedbyavertical
linelabelledWPT.
Showingandhidingwaypointgroups/symbols
Fromthechartorradarapplication:
1.PresstheWPTbutton.
2.SelectDisplayWaypoints.
3.SelectChangetoswitchbetweenGroupsandSymbols.
AlistofSymbolsorGroupsisdisplayed.
4.SelecttheGrouporSymbolyouwishtoshow/hidefromthelist.
SelectingontheSymbol/GroupwillswitchbetweenShowand
Hide.
5.RepeatStep4foreachwaypointgrouporsymbolyouwantto
showorhide.
Thelistofwaypointsandsymbolscanalsobeaccessedfromthe
ChartandRadarapplicationsmenu:
•Chartapplication:Menu>MyData>DisplayMyData>Select
WPTsToDisplay.
•Radarapplication:Menu>Presentation>SelectWPTsTo
Display.
Waypointcontextmenu
Placingthecursoroverawaypointinthechartorradarapplications
displaysacontextmenushowingthewaypoint’spositionaldata
andmenuitems.
Thewaypointcontextmenucanbeaccessedby:
•HighlightingthewaypointusingtheJoystickandpressingthe
Okbutton,or
•Selectingawaypointusingtouch—Hybridtouchmultifunction
displaysonly.
Thecontextmenuprovidesthefollowingpositionaldataforthe
waypointinrelationtoyourvessel:
•Latitude
•Longitude
•Range
•Bearing
Forinactivewaypointsthefollowingmenuitemsareavailable:
•GotoWaypoint
•EditWaypoint
•EraseWaypoint
•MoveWaypoint
•Measure
•BuildRoute
Foractivewaypointsthefollowingmenuitemsareavailable:
•StopGoto
•RestartXTE
•Measure
•BuildRoute
•
84e7/e7D/e95/e97/e125/e127/c95/c97/c125/c127
