TransducerSeaTalk
ng
SeaTalk
hs
/RayNet
Network1
SeaTalk
hs
/RayNet
Network2Videoin/out
Power/Video/NMEA
0183
e127
c95
c97
c125
c127
Powerconnection
D12 250 -1
1
2
4
5
7
3
8
6
9
1.Multifunctiondisplayconnections.
2.Poweranddatacable.
3.Connectionto12/24Vpowersupply(e7/e7Dis
12Vonly).
4.Redcable(positive).
5.Fuse.
6.Blackcable(negative).
7.Videoinputcable.
8.NMEA0183datacables.
9.Shield(drain)wire(thinblackwire;mustbe
connectedtoRFgroundpoint).
Powerdistribution
Raymarinerecommendsthatallpowerconnectionsare
madeviaadistributionpanel.
Allequipmentmustbepoweredfromabreakeror
switch,withappropriatecircuitprotection.
Allequipmentshouldbewiredtoindividualbreakers
ifpossible.
Warning:Productgrounding
Beforeapplyingpowertothisproduct,
ensureithasbeencorrectlygrounded,in
accordancewiththeinstructionsinthis
guide.
GroundingDedicateddrainwire
Thepowercablesuppliedwiththisproductincludesa
dedicatedshield(drain)wireforconnectiontoavessel’s
RFgroundpoint.
ItisimportantthataneffectiveRFgroundisconnected
tothesystem.Asinglegroundpointshouldbeusedfor
allequipment.Theunitcanbegroundedbyconnecting
theshield(drain)wireofthepowercabletothevessel’s
RFgroundpoint.OnvesselswithoutanRFground
systemtheshield(drain)wireshouldbeconnected
directlytothenegativebatteryterminal.
Thedcpowersystemshouldbeeither:
Negativegrounded,withthenegativebatteryterminal
connectedtothevessel’sground.
Floating,withneitherbatteryterminalconnectedto
thevessel’sground
Warning:Positiveground
systems
Donotconnectthisunittoasystemwhich
haspositivegrounding.
19
