6 DS600X Digital Fishfinder
Transducers are supplied with some models and optional with others. The
following transducer options are available:
:
1
supplied with some models
2.3 Selecting the Equipment Location
Mounting Location
The DS600X is waterproof to IPX7 is and designed to be mounted either
above or below deck. The unit should be protected from physical damage and
excessive vibration.
CAUTION:
Mount the DS600X in a protected area away from prolonged exposure
to rain, salt spray, and direct sunlight, but well ventilated.
When planning the installation, the following should be considered to ensure
reliable and trouble free operation:
• Access: There must be sufficient space below the unit to enable cable
connections to the panel connectors, avoiding tight bends in the cable.
• Interference: The selected location should be far enough away from
devices that may cause interference, such as motors, generators, and radio
transmitter/receivers. (See the EMC guidelines in the Preface.)
• Magnetic compass: Mount the unit at least 3 ft (1m) away from a mag-
netic compass.
• Cable runs: The unit must be located near a DC power source. The
power cable supplied is 5 ft (1.5 m), but a longer cable can be used if
desired. Refer to Section 2.4.
The maximum length of cable between the fishfinder and the transducer
unit should not normally exceed 25 ft (8 m).
• Environment: Good ventilation is required to prevent overheating.
Table 2-3: Transducer Parts
Item Part No.
Transducer Adapter Cable for L365/L470 Style Transducers E66070
Transducer Adapter Cable for hsb
2
/DSM250 Style Transducers
E66066
Transom Mount Transducer for DS400X/DS500X/DS600X (P58)
1
E66062
Bronze Thru-hull Transducer for DS400X/DS500X/DS600X (B744V)
1
E66061
