4.6GPSconnection
Dependingondisplayvariant,yourmultifunctiondisplaymay
includeaninternalGPSreceiver.Ifrequiredthemultifunction
displaycanalsobeconnectedtoanexternalGPSreceiver,
usingSeaT alk
ng
orNMEA0183.
GPSconnection—SeaTalk
ng
D12 26 1-1
SeaTalk
ng
1
2
1.Multifunctiondisplay.
2.SeaTalk
ng
GPSreceiver.
GPSconnection—NMEA0183
D12 26 2-1
NMEA 0183
1 2
1.Multifunctiondisplay.
2.NMEA0183GPSreceiver.
4.7AISconnection
AcompatibleAIScanbeconnectedusingSeaT alk
ng
orNMEA
0183.
ConnectionusingSeaTalk
ng
D12 26 3-1
SeaTalk
ng
2
1
1.Multifunctiondisplay.
2.SeaTalk
ng
AISreceiver/transceiver.
ConnectionusingNMEA0183
NMEA0183 (38400)
NMEA 0183 (4800)
3
1
2
D12 26 4-1
1.VHFradio.
2.AISunit.
3.Multifunctiondisplay.
50NewaSeries/NewcSeries/NeweSeries
