Raymarine SmartPilot X-5 ST6002 Controller User Manual

55˚
85˚
D10126-1
Display Layout
To activate the Autopilot
For Manual Control
To change the
Autopilot Heading
To follow a Route
set on a Chartplotter
standby
Press for
Manual Control
auto
Press to activate
the Autopilot
track
When the Autopilot
is activated, press
to follow a route
from a connected
navigation system.
Press again to accept
the new course
course change keys
Port 1˚ Starboard 1˚
Port 10˚ Starboard 10˚
disp
Press to display
data pages
Press for 1 second
for lamp control
Press for 3 seconds
for power off
x3x3
OK?OK?
Attach
TillerPilot
1
Remove
TillerPilot
2
2
1
3
GMA
GMA
GMA
GMA
GMA
GMA
GMA
GMA
GMA
GMA

Raymarine SmartPilot X-5 ST6002 Controller Specifications

General

Type	Autopilot Controller
Model	ST6002
Display	LCD
Keypad	Yes
Compatibility	Raymarine SmartPilot X-5
Waterproof Rating	IPX6
Power Supply	12V DC
SeaTalk	Yes
SeaTalkNG	No
Mounting	Flush mount
Weight	0.5 kg
