Raymarine SPX 30 User Manual

43
Chapter 4: SPX SmartPilot specifications
SPX SmartPilot computer specifications
Nominal supply voltage
X 10
X 30
X SOLENOID
12 or 24 V DC (fuse protected at 15A)
12 or 24 V DC (fuse protected at 40A)
12 or 24 V DC (fuse protected at 15A)
Operating voltage range
X 10, X 30, X SOLENOID
10 V to 32 V DC
Power consumption (standby)
X 10, X 30, X SOLENOID 300 mA
Gyro internal GyroPlus fitted onto circuit board as standard
Environmental conditions
operating temperature
non-operating temperature
relative humidity limit
water protection
-10°C to 55°C (14°F to 131°F)
-20°C to 70°C (-4°F to 158°F)
80%
drip resistant when mounted vertically
Storage conditions when
packed
temperature range
relative humidity limit
-5°C to 50°C (23°F to 122°F)
75%
Dimensions
X 10, X 30, X SOLENOID
(width, height, depth)
307mm (12.1 in), 195 mm (7.7 in), 70 mm (2.8 in)
Weight
X 10
X 30, X SOLENOID
1.1 kg (2.42 lbs)
2.2 kg (4.85 lbs)
Inputs
X 10, X30, X SOLENOID
fluxgate compass, rudder position sensor, NMEA 0183 v2.3,
SeaTalk, SeaTalk
ng
, power, sleep switch
Outputs
X 10, X 30
X SOLENOID
NMEA 0183 v2.3, SeaTalk, SeaTalk
ng
, drive motor, drive clutch
NMEA 0183 v2.3, SeaTalk, SeaTalk
ng
, bypass valve, solenoid drive
Raymarine drive compatibility
X 10
X 30
X SOLENOID
all Type 1 drives/pumps (excluding CR pumps) (drive voltage must
match boat’s supply voltage)
all Type 1, Type 2 and Type 3 drives / pumps (drive voltage must
match boat’s supply voltage)
CR pumps etc.
Drive motor output
X 10
X 30
continuous 10A at supply voltage
continuous 30A at supply voltage
Drive clutch output
X 10
X 30
X SOLENOID
1.2A at 12 / 24 V selectable
3.0A at 12 / 24 V selectable
2.0A at 12 / 24 V selectable
SeaTalk output
X 10
X 30, X SOLENOID
2A at 12 V (fuse protected at 2A)
3A at 12 V (fuse protected at 3A)
87072-2.book Page 43 Thursday, November 22, 2007 8:43 AM
