11
Rayvolt Hub is a very complexe
Brushless 3 phase DC Motor counting
48 different copper coils and magnets
placed on the very outer part of the
motor perimeter for the best possible
torque. The Built in Controller receive
heat and position info from the coils and
compute where to put the next load at
all time in real time within 0.001 second.
Such accuracy gives a Pure Sine Wave
Current offering an unmatched ride
comfort:
• More Acceleration
• More Torque
• More responsive
• Less Noise
• Less Vibration
• Less Consumption
Motor
The Intelligent Pedal Assist System
detects the crankset motion, sends info
in real time to the motor for it to answer
with proportional power.
There are 6 levels of assistance from
no aid to max assistance that can be
activated from EIVA’s main screen.
Those levels can be further calibrated
from the advanced setting menu.
In Auto mode, the bike will detect your
cycling environment and adjust in real
time the assistance according to the
type of hill you are climbing.
The RBS is an electronic braking system,
fitted into the brake levers, that sends a
data signal to the motor controller that
provokes a reverse effect in the motor
converting torque into resistance using
the wheel inertia to generate electricity
and recharge the batteries.
In simple words, the regen braking is
acting like an ultra powerful dynamo
when the levers are pulled.
The RBS sensibility can be adjusted from
EIVA by adjusting the maximum regen
current. Go to chapter … on EIVA user’s
manual to setting the RBS.
Regen Brake System
