properly adjust and tighten the nuts
and bolts that affi x the forks can
cause you to lose control and fall.
Your electric motorbike may not have a fully charged battery; therefore it is a good idea to charge the battery
• Initial charge time: 12 hours • Run time: up to 40 minutes
• Recharge time: up to 8 hours, • Average battery life: 250 charge/discharge cycles
depending on the level of depletion
Plug the charger port into the
port on the electric motorbike.
The charger works with the power
switch in either the on or off
Plug the charger plug into a wall
disconnect your electric motorbike
from the charger before cleaning
look like the one illustrated,
your unit has been supplied
with an alternative charger.
The specifi cations and charging
procedure would not change.
The charger has a small window
with one LED or two LEDs to
indicate the charge status. Refer
to the illustration on the charger
unit for the actual “charging” and
“charged” status indications for
Chargers have built-in over-charge
protection to prevent battery from
Be sure to properly align the
groove on the charger input
plug with the corresponding
socket on the case; otherwise,
no charging action will occur.
Attaching the Front Forks
Insert the spacer sleeves on the
top and bottom of the frame.
Slide the fork into position and
insert the steering bolt. The bolt
must go through the washer and
spacer sleeve and between the
steering bearings inside the frame.
Install washer and nut onto
steering bolt. Tighten until snug,
then back off slightly to allow the
steering to rotate freely with no
