3
ASSEMBLY AND SET-UP
q Attaching the Handlebars
2
Depress the push button
located on the front fork and
insert the handlebar stem until
the button locks securely into
the fork.
3 Adjust the tension of the
quick release to where you can
close the lever all the way to
secure the stem.
1 Open the quick release.
Note: Make sure the cables/
wires are out of the way before
inserting the stem into the fork.
4 Using a bicycle style tire pump
equipped for a Schrader-type
valve, inflate the front tire to the
PSI indicated on the sidewall of
the tire.
1 Use the valve extender
located inside the end of the
right handlebar grip.
2 Open the round cover
located on the chain cover
by sliding the cover upward.
Align the opening in the drive
sprocket with the valve stem.
Thread the adapter completely
onto the valve stem and attach
the pump. Inflate to the PSI
indicated on the tire sidewall.
3 Remove valve extender
immediately after inflating and
close the round cover.
q Inflating the Tires
Tires are inflated when shipped, but they invariably lose some pressure between the point of
manufacturing and your purchase. Always inflate tires to the correct PSI before first time use.
Rear Tire
WARNING: Failure
to remove the valve adapter
after inflating will cause the
inner tube and/or adapter to
be severed by the rear drive
sprocket.
Note: If you lose the valve
extender, one can be purchased
at almost any auto parts store.
Note: The pressurized air
supplies found at gasoline
stations are designed to inflate
high-volume automobile tires.
If you decide to use such an air
supply to inflate your electric
scooter tires, first make sure
the pressure gauge is working,
then use very short bursts to
inflate to the correct PSI. If you
inadvertently over-inflate the
tire, release the excess pressure
immediately.
Front Tire

Other manuals for Razor e300

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Razor e300 and is the answer not in the manual?

Razor e300 Specifications

General IconGeneral
FoldableNo
Maximum speed24 km/h
Product colorSilver
Built-in display-
Maximum load weight100 kg
Recommended age (min)13 yr(s)
Battery life40 min
Battery voltage24 V
ManualYes
Weight and Dimensions IconWeight and Dimensions
Depth430 mm
Width1040 mm
Height1070 mm
Weight21000 g
