Remove Nuts from Towel Bar and Attach onto Side
Shelves
Remove Bottom Shelf and Axle
1
DO NOT RETURN TO PLACE OF PURCHASE.
For assistance, call 1.800.694.0013 toll-free. Please have
your owner’s manual and model number available for
reference.
Note: The model number is printed on a label which can be found on
the bottom shelf.
Assembly Tips:
1. Select an area where you will assemble this product. To
protect components, choose a smooth surface that’s free of
cracks or openings.
2. Spread out all parts.
3. Tighten all hardware connections by hand first. Then, before
completing each step, go back and fully tighten all hardware.
Be careful not to over-tighten. That could damage surfaces or
strip threads.
4. For best results, complete each step in the order presented.
To complete assembly you will need:
• (1) Leak detection solution (instructions on how to make the
solution are included in the “Operating Instructions” section of
this manual).
• (1) Precision-filled LP gas grill tank with Acme Type 1 external
threaded valve connection (standard grill size) (not included).
Typical assembly is approximately 30 minutes.
W CAUTION: Two (2) people are required for
assembly.
Assembly Instructions
2
Unlock Side Shelves
Open Side Shelves
Open right side shelf first, then left side shelf. Make sure side shelves are pushed all
the way down.
Note: support springs may cause the side shelves NOT to rest completely flush with
the side handles.
W CAUTION: Hold side shelf securely while opening. Do NOT
release until fully extended.
W CAUTION: Maximum side shelf weight is 33 lbs (15 kg).
4
Close Side Shelves
Close left side shelf first, then right side shelf.
W CAUTION: Hold side shelf securely while closing. Do NOT
release until fully closed.
Lock Side Shelves
1
1
2
2
3
2
1
1
1 2 3
2
To Next Page
