Razor Pocket Mod Petite User Manual

10
REPAIR AND MAINTENANCE
Front Wheel Replacement
Tools Required: Two (2) 14 mm Wrenches
1 Remove the nuts on both sides of
the front axle using a 14 mm wrench
then remove the lock washers and
remove the wheel from the fork.
4 Tighten the nuts using two (2)
14 mm wrenches.
3 Insert tab on the lock washer (B)
into the hole (A) on the front fork and
then place the nuts (C) on top of the
lock washer (B).
2 Insert the new wheel into the
front fork with the lock washers on
the outside of the fork. See step #3.
A
B
C

Razor Pocket Mod Petite Specifications

General

Battery	12V sealed lead-acid, rechargeable
Throttle	Twist-grip
Brake	Hand-operated, rear
Frame	Steel
Grips	Soft rubber
Battery Life	Up to 40 minutes of continuous use
Motor	100-watt, high-torque
Weight Capacity	110 lbs
Age Recommendation	7+
Fairings	Plastic
Kickstand	Retractable
