Need Help? Visit our website for replacement parts, product support, a list of authorized service centers in the US and customer service contact information
at www.razor.com. Please have the product I.D. code (located on the white label of your product) available for better assistance. Additional Customer
Service contact information is listed at the back of this manual.
5
ASSEMBLY AND SET-UP
Positioning the Brake Lever
Tool Required: 5 mm Allen Wrench
Attaching the Front Fender and the Front Wheel
Tools Required: Phillips Screwdriver, Two (2) 14 mm Wrenches
1 Adjust angle of the brake lever to
a comfortable position for the rider
by turning back and forth.
1 Remove the plastic packing
material from the front fork.
4 Insert the tab on the lock washer
into the hole on the front fork.
2 Securely tighten the bolt using a
5 mm Allen wrench.
2 Insert the front fender into the
front fork and tighten the screw using
a Phillips screwdriver.
5 Tighten the nuts using
two (2) 14 mm wrenches.
3 Insert the wheel into the front
fork with the lock washers on the
outside of the fork.
To Next Page
