Page #15 background imageLoading...
Page #15 background image
2 3 4
5 20
1 1
6
7
9
10
8
11 12 12-1
15 17
18
16
19
14
13
Need Help? Visit our website for replacement parts, product support, a list of authorized service centers in the US and customer service contact information
at www.razor.com. Please have the product I.D. code (located on the white label of your product) available for better assistance. Additional Customer
Service contact information is listed at the back of this manual.
12
POWER CORE E100 SERIES ELECTRIC SCOOTER PARTS
Keep your electric scooter running for years with genuine Razor parts. Visit our website or e-mail us for more information on spare part availability.
(Specifications subject to change without notice.)
1. Handlebar Grips (Right/Left)
2. Single-Speed Twist-Grip Throttle
3. Stem
4. Brake Lever Assembly
5. Battery 24V (2 12V)/6A
6. Collar Clamp
7. Headset (Upper/Lower)
8. Front Fork
9. Front Caliper Brake With Brake Pads
10. Front Wheel Complete
11. Kickstand
12. Rear Wheel with Hub Motor Complete
12-1 Motor Cover
13. Deck Plate
14. Battery Strap
15. Battery Tray
16. On/Off Switch
17. Charge Port
18. Reset Button
19. Control Module
20. Seat Post with Seat
(Power Core E100S only)

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Razor POWER CORE E100 Series and is the answer not in the manual?

Razor POWER CORE E100 Series Specifications

General IconGeneral
Battery24V (two 12V) sealed lead-acid, rechargeable
Max Speed10 mph (16 km/h)
Run TimeUp to 60 minutes of continuous use
FrameSteel
Weight Limit120 lbs (54 kg)
Age8+
ThrottleTwist-grip
KickstandRetractable
Charging Time12 hours
BrakeHand-operated front brake
GripsSoft, rubber
Tires8-inch pneumatic front tire
