9. Sensitivity control Adjustable (level 1-level 5 for low-high)
10. Lock shade Yes
11. Auto shade Ye s
12. Arc sensors 4
13. Ambient light sensor 1
14. Grind function Yes
15. Power Supply Solar Cell, Replaceable Battery(CR2450*2PCS)
16. Operating Temperature -10°C~65°C (14°F~149°F)
17. Inside PC lens 108 x 108 x 1 mm (4.25" x4.25")
18. Outside PC lens 114 x 133 x 1 mm (4.5" x5.25")
19. Warranty 2 years
OPERATION INSTRUCTION
BEFORE USE
-Check for light tightness and check the inside & outside protection lens are clean and that no
dirt is covering the sensors on the front of the auto-darkening-filter (ADF) cartridge.
-Make sure the protection films on both inside & outside protection lens are removed.
-Inspect all operating parts for signs of wear or damage. Any scratched, cracked, or pitted
parts should be replaced immediately.
1.AUT
O SHADE
At AUTO mode ,ADF will adjust to appropriate shade according to the welding arc
aut
omatic.
Press Shade button(position 25) on ADF ,ADF will be changed to AUTO mode . .
At AUTO mode ,the shade can be corrected up 2 shade(highest is shade 13) and down 2
shade (lowest is 5) if necessary . Clockwise turning the shade knob (Position 8), shade can be
corrected up ;anticlockwise tuning the shade knob ,shade can be corrected down . LED
display will show the current shade number (Position 24) .
2.Manual SHADE
At Manual mode ,ADF will adjust to appropriate shade by manual control
Press Shade button (position 25) on ADF, ADF will be changed to Manual mode from
AUTO mode . move the switch (position 33) on potentionmeter ,Shade range will be changed
between range 5-9 and range 9-13 .Led display will show the shade range take turns.
At range 5-9 mode ,the shade can be adjusted from shade 5 to shade 9 by turning the
external shade knob. Clockwise turning the shade knob (Position 8), shade can be adjust
up ;anticlockwise tuning the shade knob ,shade can be adjusted down .
At range 9-13 mode ,the shade can be adjusted from shade 9 to shade 13 by turning the
external shade knob. Clockwise turning the shade knob (Position 8), shade can be adjusted
up ; anticlockwise tuning the shade knob ,shade can be adjusted down .
3.G
rind mode
ADF can be adjusted between welding and Grind mode
At welding mode , pressing and holding the external GRIND button 2 sec (Position 7).
