RBI FlexCore CK 5000 User Manual

DEFAULT SETTINGS & MENU ITEM DESCRIPTIONS HeatNet Control V3
Page 113
LOWEST FLOW
BY BOILER
TYPE
0-500 GPM
This is the automatic value loaded and will equal the lowest flow
required for this boiler (it is adjustable). It should be equal to the
lowest flow of the largest boiler in the system.
HIGHEST FLOW
BY BOILER
TYPE
Currently not used.
FULL SCALE
PER FLOW
METER
0-1600 GPM
Enter the value of the full scale reading on the calibration card that
came with the flow meter.
FLOW FACTOR
BY BOILER
TYPE
PPG
Currently not used.
CONFIGURE INTERLKS
The 24 VAC interlocks can be enabled or disabled for reporting.
PRODUCT:
MB/MW 500
MB/MW 500
-
CK 9000
The product type allows configuration of the control for a product
(and given a personality). This allows the control to be
used/interchanged with many products. The following fields will be
adjusted for the personality of the product.
CONDENSING
YES
This defines a boiler as condensing or non-condensing.
BTU INPUT
PER BOILER
TYPE
This is the BTU input rating of the boiler. This value is not used
with this released version and is displayed only for reference. Future
releases may incorporate this feature. Check the revision history
sheet on the website.
BLOWER
VFD
VFD, AMETEK, EBM
This is the blower type associated with the product. This should not
be changed manually. Due to FIII/Fusions using Variable Frequency
Drives, this setting needs to be adjusted for Whirlwind (Ametek)
models. The default is for a VFD except for the FlexCore CK
Series.
MASS
MEDIUM
LOW,MEDIUM,
HIGH
This defines the mass of the boiler. This value is not used with this
version and is displayed only for reference and future applications.
Check the revision history sheet on the website.
TURNDOWN
5:1
3:1, 4:1, 5:1
This is the turndown of the boiler. For the FlexCore CK -Series the
default is 5:1 and determines the minimum firing percentage.
5:1 = Min 20%, 4:1 = Min 25%, 3:1 = Min 33%.
NOTE: The boiler must be set up for operation at this Turndown
rate using the Calibrate settings. This TURNDOWN setting only
controls the displayed percentage.
ALTITUDE
LESS THAN
2000FT
LESS THAN 2000
FT,
GREATER THAN
2000 FT,
GREATER THAN
4000 FT
This is the Altitude in feet of where the boiler is installed. On
Ametek Blowers it limits the blower output for low altitudes and
allows a higher output at higher altitudes. This setting sets the upper
range limit of the MAX VFD setting.
