Line sequence table
■
Somewireusethewater-proofconnector,usersarenotabletoseethe
inside color.
Operation Cautions
Be care of the safety use. Don’t attempt to release the connector
when battery is on power.
◆ Try to avoidhitting.
◆ Do not modify system parameters to avoid
parametersdisorder.
◆ Make the display repaired when error codeappears.
Attached list 1: Error code definition
Error Code Definition
21 Current Abnormality
22 Throttle Abnormality
23 Motor Abnormality
24 Motor Hall Abnormality
25 Brake Abnormality
30 Communication Abnormality
Attached list 2：Power assist table
Level
Level
Item
1 2 3 4 5 6 7 8 9
0-3/1-3 50%
74%
92%
— — — — — —
0-5/ 1-5
50%
61%
73%
85%
96%
— — — —
0-7/ 1-7
40%
50%
60%
70%
80%
90%
96%
— —
0-9/ 1-9
25%
34%
43%
52%
61%
70%
79%
88%
96%
Line sequence Color Function
1 Red（VCC） +
2 Blue(K) Lock
3 Black(GND) -
4 Green(RX) RX
5 Yellow(TX) TX
