42
Technical Data
Model Pluto R / Pluto C2
General
Type Pedelec
Curb weight approx. 16.5 kg depending on equipment
Perm. Total weight max. 120 kg
Dimensions (L x W x H) mm 1870 x 630 x 1210
Top speed about 32 km / h
Frame aluminum trekking frame 28 "
Tires front and rear 700C x 28C
Rims front and rear 700C x 36H
Tire pressure front and rear min. 3.5 bar
Brake, front TEKTRO disc brake
Brake, rear TEKTRO disc brake
Driving
Front sprocket set 48 teeth
Chain sprocket rear 11 - 32 teeth
Chain 1/2 x 3/32 108 links
Pedal drive pedals
Bottom bracket cassette bottom bracket with external speed sensor (12-point magnetic
sensor)
Shift SHIMANO ALTUS , 9-speed derailleur, operated by
Shift lever on the handlebar
Display Display with display for program selection and remaining capacity
display,odometer, trip odometer
Mode 9 modes with speed limit
From approx. 25 km / h there is no more motor support Start-up and
pushing assist 6 km / h
